Laboratory Dedicated 316 Stainless Steel Multi
SHANGHAI BAOXING BIO-ENGINEERING EQUIPMENT CO;Ltd Shanghai Baoxing Bio-Engineering Equipment Co.,Ltd.(BXBIO)is an experi
Basic Info.
Model NO. | BIOTECH-10/20/50/100L/500L/1000L/5000L |
Customized | Customized |
Condition | New |
Warranty | 1 Year |
After-sales Service | Online Support/Visit Client′;S Plant Site |
Heating Method | Steam /Electrical /Hot Water |
Tank Layer | Single Layer/Jacket Type /Double Jacket |
Top Mounted Agitator | Propeller /Anchor/Scraper /Emulsifying Type |
Cooling Method | Chiller/Cooling Water |
Food Product | Juice ,Milk ,Honey,Chocolate ,Cream ,Ketup,Yogurt |
Output | Liquid Solution/Suspension/Cream |
Function | Mix One or Several Materials Together |
Core Componentes | Mixing Agitator System ; Heating & Cooling Jacket |
Transport Package | Export Standard Package |
Specification | 5L-10000L |
Trademark | BAOXING |
Origin | China |
HS Code | 8479820090 |
Production Capacity | 100 Sets/Month |
Product Description
SHANGHAI BAOXING BIO-ENGINEERING EQUIPMENT CO;Ltd
Shanghai Baoxing Bio-Engineering Equipment Co.,Ltd.(BXBIO)is an experienced manufacturer of bio-reactors(fermentor),bioprocess controllers and a provider of bio-engineering services.
BXBIO and its engineering team with experience of designing and manufacturing fermentors devote themselves to studying, improving, and development of fermentors, the BIOTECH series fermentors and controllers have satisfied their users all over the world because of our advanced and high quality products and the satisfying timely after services. The BXBIO products have been widely used in education,scientific research, bio-manufacture etc;.and there are thousands BXBIO products working perfectly nowadays.
Application:This fermentationtank is ideal system for production of bacteria, yeast, enzyme,and fung,etc in aerobic and anaerobic cultures.This series of products suits for various kinds of microbiology lab, pilot and industrial scale fermentation. User can choose appreciate model according to Client s detail requirement. We have model from 5L---50000L.
Structure:
This fermentation tank include fermentation tank, pressure Aeration Pressure feed antifoam rpm PH Do temperature control system, heating system and control system.
Parameter:
Model | 30L | 50L | 100L | 200L | 500L | 1000L | 2000L | 3000L | 5000L | 10000L | 50000L |
Diameter mm | 300 | 300 | 400 | 500 | 700 | 900 | 1200 | 1300 | 1500 | 1800 | 3100 |
Height mm | 1600 | 1700 | 2000 | 2300 | 2600 | 3000 | 3800 | 4300 | 4500 | 5300 | 8000 |
Filling capacity | 65%-75% | ||||||||||
Inside Pressure Mpa | 0. 2 | ||||||||||
Jacket pressure Mpa | 0.3 | ||||||||||
Cool method | By jacket | By pipe | |||||||||
Mix speed rpm | 400 | 400 | 400 | 360 | 300 | 220 | 180 | 160 | 145 | 125 | 110 |
Motor Power kw | 0.55 | 0.55 | 0.75 | 1.1 | 1.5 | 2.2 | 3 | 4 | 5.5 | 13 | 55 |
1 How much liter fermentation tank do you need?
2 Do you need to check the PH and oxygen degree of the fermentation tank?
3 What way do you want to heat the fermentation tank ? By steam or electric?
4 How much speed of the mixer do you need?
5 When do you need this machine?
Our service:
1 We will design the fermentation tank according to your raw material requirement
like you need PH meter.DO meter or not.
2 We will test the pressure in our factory. We test all the things then delivery the machine to you.
3 We have engineer to go your side to install the machine and train your operator, We can analysis the temperature, PH degree, Oxygen degree and so on.
