3.5mm or 4.5mm Full Stroke Optional No/Nc Electric Thermal Wax Actuator

Overview Product Description 3.5MM or 4.5MM Full Stroke Optional NO/NC Electric Thermal Wax Actuator HTW-TV02-VA Thermal

Send inquiry

Overview

Basic Info.

Model NO.	HTW-TV02-VBO/C
Acting Type	Wax
Material	PA6110
Customized	Non-Customized
Structure	Rack and Pinion
Protection Class	IP40
Power Consumption	1.1va
First Fully Open	5~6.5 Minutes ( at 25ºC)
Lead Wire	1m Length (2-Core)
Net Weight	94G
Max Impact Current	1.2A/0.9A/0.7A
Direction	Downward
Working Ambient Temperature	-0.5ºC~60ºC
Connector	M30*1.5
Color	White
Transport Package	Carton
Specification	403228
Trademark	Neutral/Customized
Origin	China
HS Code	84159090
Production Capacity	500000/Year

Product Description

3.5MM or 4.5MM Full Stroke Optional NO/NC Electric Thermal Wax Actuator

HTW-TV02-VA Thermal Valve Actuator is designed to control the open/close of the pipe of chilled/hot water for HVAC system so as to control the indoor temperature and maintain a thermal room temperature. It is installed on the chilled/hot water pipe, and the valve is controlled to open or close via the signal send from thermostat. The thermostat sends a signal to open the thermal valve to cool/ heat the room via heat exchange from the cooling/heating media, like chilled/heating water.

Product Parameters

3.5mm or 4.5mm Full Stroke Optional No/Nc Electric Thermal Wax Actuator
